Our gearboxes.
Economical and efficient.

Maximum variety

KLC Drive Technologies - supplies high-performance gearboxes for drive systems in industrial automation.

We offer products in a variety of technologies in order to be able to offer the ideal product for every drive task. Our partners develop and produce in large quantities, thereby achieving attractive costs that give our customers a competitive advantage. Performance and quality must not be sacrificed in the process!

Planetary gear
Product Overview

Highly precise, robust and dynamic.
Sizes: 42mm - 255mm
Nominal torque: 3Nm - 2150Nm
Accuracy: up to <1 arcmin
Special designs for
- Food industry
- Wheel drives
- Rotary indexing tables

Various industrial metal planetary gearboxes
Spur gear
Product Overview

Short design with high efficiency
Power: 0.09kW - 90kW

Industrial electric motor with gearbox and drive shaft
Cycloidal drive
Product Overview

Extremely short, highly accurate and dynamic.
Proven in robotics,
Machine tools and mechanical engineering.

Size: 124mm - 475mm
Nominal torque: 98Nm - 4900Nm
with and without hollow shaft

Industrial metal planetary gearboxes on a white background
Worm gear
Product Overview

Compact right-angled transmission.
Self-locking for larger
Translations.

Size: 25mm - 150mm
Power: 0.09kW - 4kW

Industrial gearbox housing with worm gear on a white background
Bevel gear
Product Overview

The advantage of a bevel gearbox is that it can efficiently transmit rotary motion between intersecting axes (usually at a 90º angle).

Industrial gearbox with two shafts and flange housing

Industrial gears

Large gear
Product Overview

Large gear

- Spur gear, bevel gear, worm, planetary, cycloid
- up to 480,000Nm
- with and without motor

Four industrial electric motors with gearboxes on a white background

Gearbox product portfolio

The present portfolio comprises a broad spectrum of DC geared motors, for industrial and commercial applications. The product range covers both brushed and brushless (BLDC) drive principles and combines these with various gearbox types. Thanks to the modularity of the series, transmission ratios can be customised,

output torque and design can be flexibly adapted to the respective application. All units are designed for smooth running, a long service life and easy integration into compact systems - from service robotics and medical devices to solar tracking systems and access control.

Product Overview

High-precision planetary gearboxes (Servo & Automation)

Category
Planetary inline shaft output
Most important characteristic values
42-220 mm flange - 14-2,008 Nm - i = 3-100 (1-/2-stage) - P0 <1 / P1 <3 / P2 =97% Efficiency
Typical applications
Servo/stepper drives, CNC, robotics, packaging, medicine
Category
Planetary inline flange outlet
Most important characteristic values
42-220 mm flange - 14-2,008 Nm - Electrolytic nickel-plated - Full needle bearing Planetary
Typical applications
Servo applications with direct flange connection
Category
Planetary Inline Compact
Most important characteristic values
42-180 mm flange - Shortest overall length - Optimised weight - i = 3-100
Typical applications
Space-critical servo applications, lightweight high dynamics
Category
Planetary inline hollow shaft
Most important characteristic values
Hollow shaft output - Cable feed-through through drive train - IP65
Typical applications
Robot joints, rotary tables, collaboration robots
Category
Planetary 90° angle shaft output
Most important characteristic values
42-180 mm flange - 14-1,200 Nm - i = 3-200 (1-/2-stage) - P0/P1/P2 - IP65
Typical applications
Servo angular axes, portal machines, printing machines
Category
Planetary 90° angle flange outlet
Most important characteristic values
60-140 mm flange - 42-650 Nm - Electrolytic nickel-plated - High bending stiffness
Typical applications
Direct flange connection 90°, linear axes
Category
Planetary AGV module Integrated
Most important characteristic values
Up to 300 Nm - High radial bearing capac. - Optimised inertia mod. - Compact
Typical applications
AGV, AMR, mobile robots, automated vehicles
Category
Planetary Delta Robot Integrated
Most important characteristic values
Up to 310 Nm - Extremely low backlash - Increased output stiffness - Low vibration
Typical applications
Delta robots, high-speed picking, parallel kinematics
Category
Planetary + pinion output Integrated
Most important characteristic values
Integrated pinion - Lower radial run-out - Simple installation
Typical applications
Rack and pinion drives, linear axes, portal machines
Category
Planetary + servo motor all-in-one
Most important characteristic values
Motor + gearbox in one housing - Optimised inertia tuning
Typical applications
Compact servo axes, OEM combination solutions

Spur gears (industry)

Most important characteristic values
Up to 26,900 Nm - Foot and flange mounting - Servomotor connection optional - Solid/hollow shaft
Typical applications
Conveyor systems, pumps, construction, general mechanical engineering
Most important characteristic values
GG20/GGG40 housing - 58-62 HRc teeth - Up to 6-stage expandable - IEC B5/B14
Typical applications
Mixers, conveyors, packaging, general industry
Most important characteristic values
80-15,000 Nm - 10 sizes - 0.1-400 rpm - 2-3 stages in the same gear. - IEC B5/B14
Typical applications
Conveyor systems, pumps, agitators, textiles, general mechanical engineering
Most important characteristic values
Directly on output shaft - Pulley/chain drive possible - Simplified installation
Typical applications
Belt conveyors, mixers, agitators, pumps
Most important characteristic values
Coaxial design - Flat compact length - Foot and flange mounting - Optional servo motor connection.
Typical applications
Space-saving drives, conveyor technology, packaging

Cycloidal precision gears (robotics & CNC)

Most important characteristic values
15-700 Nm - Two-stage planetary + cycloidal - 5x overload torque - High power density
Typical applications
Industrial robots, CNC machines, non-standard automation
Most important characteristic values
20-1500 Nm - Two-stage planetary + cycloidal - 5x overload torque - Compact & flat
Typical applications
Industrial robots, CNC, deflection machines
Most important characteristic values
10-1200 Nm - Two-stage - Hollow shaft for cable guide. - 5x overload torque - <=1 arc.min. backlash
Typical applications
Industrial robots, rotary tables, precision automation
Most important characteristic values
20-320 Nm - Gear ratio 20-40 - <=1 arc.min. - Maintenance-free - Pre-lubricated
Typical applications
Machining centres, tool changers, high-precision rotary tables
Most important characteristic values
10-200 Nm - Hollow shaft for cable guide - 5x overload torque - 2.5x fitting torque
Typical applications
High-precision rotary tables, positioning systems, medical technology
Most important characteristic values
20-40 Nm - Gear ratio 20-40 - Integr. clutch mount - High shock load capacity
Typical applications
Delta robots, high-speed picking, parallel kinematics
Most important characteristic values
Compact overall length - High transmission ratio achievable in one stage - High shock load capacity
Typical applications
Precision machines, servo applications, rotary tables
Most important characteristic values
Solid/hollow shaft - B3/B5/B14 - Torque support - Grease lubrication up to size 611 - All mounting positions
Typical applications
Heavy-duty conveyors, cranes, mining, cement, recycling, pumps

Helical bevel & worm gearboxes (90° shaft angle)

Most important characteristic values
Helical/curved teeth - GGG40/GG20 housing - 58-62 HRc teeth - B5/B14 flange
Typical applications
Cranes, conveyor systems, textiles, wood-based materials, food industry
Most important characteristic values
Two-stage (spur + worm) - Foot and flange mounting - 21NiCrMo2 + bronze - Shrink disc option
Typical applications
Conveyor systems, mixers, wood-based materials, chemicals, foodstuffs
Most important characteristic values
Gear ratio 7.5-100 - Self-locking usable - Aluminium body - 16MnCr5 + bronze
Typical applications
Food, textiles, packaging, small drives

Planetary & heavy-duty gearboxes (industry)

Most important characteristic values
1,000-50,000 Nm - i = 3.5-3,000 - 10 sizes - electr. or hydr. motor - IEC B5/C26/M46
Typical applications
Hoists, mixers, mobile machines, wind power, presses
Most important characteristic values
GGG40 housings & flanges - High power density - Bevel/screw stage optional - Mobile applications
Typical applications
Cranes, construction/mining machinery, wind power, metal forming
Most important characteristic values
2,000-480,000 Nm - Parallel or 90° axes - GGG 40-50 housing - Pressurised circulating lubrication - Heat exchanger
Typical applications
Mining, cement, heavy-duty conveyors, mills, presses

Application-specific & special gearboxes

Most important characteristic values
Load capacity 1-60 t - FEM-ISO-compliant - Aluminium or GGG40 - FU-suitable, IP55
Typical applications
Indoor cranes, trolleys, hoists, construction industry
Most important characteristic values
Extruder-optimised design - High axial loads - Pressure-tight design
Typical applications
Plastic/rubber extruders, calendering systems
Most important characteristic values
Feed mixer optimised - Adapted materials and lubrication concepts
Typical applications
Poultry feeding, feed mixer, agriculture
Most important characteristic values
Vertical installation position - Coaxial design - High efficiency
Typical applications
Agitators, mixers, vertical conveyors, process industry

Micro reduction gears (small drives)

Category
Planetary low noise Micro design
Most important characteristic values
Low noise emission - High shock load capacity - Customisable transmission ratio
Typical applications
Industrial machinery, renewable energy, small robot drives
Category
Augers Micro design
Most important characteristic values
Very compact installation space - Self-locking use - Versatile housings
Typical applications
Intelligent office equipment, medical technology, consumer appliances
Category
Spur gear Micro design
Most important characteristic values
High efficiency - Compact installation space - For DC/stepper motors
Typical applications
Office equipment, small robots, household
Category
Bevel gear Micro design 90° angle
Most important characteristic values
90° centre angle - Compact format - For small drives
Typical applications
Medical technology, consumer appliances, small automation
Category
Cycloidal micro design
Most important characteristic values
High transmission ratio achievable in one stage - Very compact installation space
Typical applications
Precision miniature drives, robotics, medical technology
